Dornier Do-24T

Down load the Brochure and Information Sheet

Short Kit Includes:

Plan Sets color & b/w, Construction Set, Construction Notes, Builder’s Material List, and Laser cut wood parts,



Options Includes:

Laser cut special hardware,

Composite cowlings, nacelles and pulled turrets by SC Models.



General Information

Project Scale                          1:8

Wing Span                              132.625" [3368.68 mm]

Fuselage Length                     108.1875" [2747.96 mm]



Propulsion System (Electric 3 sets)

Motors                                     ~ Hyperion z4035-18 brushless outrunner

Propellers                                ~ Zinger 3 Bladed 16-10

Batteries                                  ~ 2 series 5000MAH-6s-C30





Fuselage

Air Frame ~ 1/8” & 1/4” Liteply w/ 1-1/2” CF Tail Boom tube

Formers ~ 1/8" Liteply

Stringers ~ 1/8” Balsa

Keels & Backbone ~ 1/8" Liteply, keel w/ strike plate 1#8" Alum

Sheeting ~ Topside 3/32" balsa w/ glass & epoxy resin

Sheeting ~ Bottom 1/8" Balsa w/ 2 layers glass & epoxy resin



Wing

Sections ~ tip sections removable at start of sweep. Center wing attached to fuselage.

Ribs ~ 1/8" & 1/4" Balsa, Birch & Liteply

LE ~ 1/4" Liteply

TE ~ 1/32" Birch ply.

Spars ~ "I" beams 1/8" Liteply, connectors CF tubes & Phenolic sleeves

Sheeting 3/32" balsa w/ glass & epoxy resin



Vertical & Horizontal Stabilizer

Ribs ~ 1/8" & 1/4" Balsa, Birch & Liteply

LE ~ 1/8" Birch ply

TE ~ 1/32" Birch ply

Spars are 1/8" ~ 1/4" Liteply, 1/4" & 3/16" Balsa & 3/16" CF sq. stringers

Sheeting 3/32" balsa w/ .58 oz. glass w/ epoxy resin





Composites

Pictured are the three turret plugs for pulling the clear plastic parts, cowl mold and the naceel half schell mold.and the half schell mold. These are the great work of SC Models!

Do-24T plugs and molds

Chick On Photo For Info
